Bose DesignMax DM6PE 6.5" High-Power Pendant Loudspeakers, Pair - Black or White

Original price £828.00 (inc. VAT) - Original price £828.00 (inc. VAT)
Original price £828.00 (inc. VAT)
£828.00 (inc. VAT)
£828.00 (inc. VAT) - £828.00 (inc. VAT)
Current price £828.00 (inc. VAT)
SKU BOSEDM6PEW
Colour: White
DETAILS

The Bose DesignMax DM6PE 6.5" High-Power Pendant Loudspeakers are designed to deliver rich, full-range audio in both indoor and outdoor commercial environments, including retail stores, restaurants, conference centres, and hospitality venues.

Featuring a coaxial two-way design, each 125-watt speaker is equipped with a 6.5-inch woofer and a 1.25-inch tweeter, delivering a wide frequency range of 62 Hz to 20 kHz. The DM6PE utilizes Bose's Dispersion Alignment system to ensure consistent sound coverage throughout the room, providing an optimal listening experience without the need for additional DSP or EQ.

Constructed with engineered plastics and rated IP55 for outdoor use, the DM6PE is built to withstand various weather conditions. Its sleek design includes a recessed single-point suspension system for a modern and attractive appearance. Available in black or white with a minimum-bezel grille and a removable logo, these pendant loudspeakers blend seamlessly into any setting while providing high-quality audio performance.

Bose DesignMax DM6PE Key Features:

  • Full-Range Audio Performance: With a coaxial 6.5-inch woofer and a 1.25-inch tweeter, the DM6PE delivers a frequency range of 62 Hz to 20 kHz, ensuring rich lows and clear, intelligible highs. The Dispersion Alignment system aligns the acoustic pattern of the woofer with that of the tweeter for consistent sound coverage.

  • Outdoor-Ready: Rated IP55 for outdoor use, the DM6PE is designed to withstand various weather conditions. The weather-treated drivers, aluminium grille, and weather-resistant input cover make it suitable for outdoor installations in covered areas.

  • Sleek, Modern Design: The DM6PE features a recessed single-point suspension system, giving it a sleek and attractive appearance. Available in black or white with a rotatable and removable logo, the loudspeaker easily blends with any room design.

  • Flexible Installation: The DM6PE comes with a Euroblock connector and a single suspension attachment point, allowing for straightforward installation. Its 115° conical coverage pattern ensures even sound distribution across the area.

  • Versatile Applications: Ideal for a wide range of commercial settings, including retail stores, restaurants, conference centres, performing arts venues, and hospitality spaces. The DM6PE can be combined with other DesignMax models to create a tailored sound solution.

Enhance Your Commercial Audio Experience
The Bose DesignMax DM6PE Pendant Loudspeakers offer exceptional sound quality and versatile design, making them a perfect choice for enhancing the audio atmosphere in any indoor or outdoor commercial space. With their robust build, elegant design, and superior sound performance, they provide a reliable audio solution for diverse environments.

Choose Bose for Professional Audio Solutions
With the Bose DesignMax DM6PE, you get a blend of high-quality sound, durability, and sleek aesthetics. Whether you're setting up an audio system for a restaurant or an outdoor patio area, these pendant loudspeakers deliver the performance and reliability Bose is known for.

In the Box:

  • 2 x DesignMax DM6PE Pendant Loudspeakers (Black or White)
  • 2 x Weather-Resistant Input Covers
  • 2 x Suspension Cables (4.5m)
  • 4 x Cable Ties
  • 1 x Installation Guide
SPECS & DOWNLOADS

Bose DesignMax DM6PE PDF Spec Sheet > DOWNLOAD HERE

Bose DesignMax DM6PE Specifications

Physical:

  • Colours: Black (similar to RAL 9005), white (similar to RAL 9003)
  • Enclosure Material: Engineered plastics, highly UV fade-resistant
  • Environmental Testing: Outdoor per IEC 529 IP55 (suitable for use outdoors in wet locations), includes aluminium grille to prevent red corrosion and weather resistant input cover
  • Grille Material: Perforated steel, powder-coated finish
  • Ingress Protection: IP55
  • Logo: Rotatable, removable
  • Mounting/Rigging Provisions: 1 suspension attachment point, 1 safety cable attachment point
  • Net Weight: 12.5 lb (5.7 kg), single
  • Operating Temperature: -25 °C to 65 °C (-13 °F to 149 °F)
  • Product Dimensions (H×W×D): 12.1 in × 14.8 in (308 mm × 375 mm), loudspeaker diameter × depth
  • Shipping Weight: 33.1 lb (15.0 kg), pair

Performance:

  • Frequency Range (-10 dB): 65 – 20,000 Hz
  • Coverage, Horizontal: 115° conical
  • Maximum SPL at 1 m: 110 dB
  • Nominal Impedance: 8 Ω (transformer bypass)
  • Power Handling, Continuous: 100 W
  • Power Handling, Peak: 400 W
  • Sensitivity (SPL/1 W at 1 m): 89 dB
  • Transformer Taps, 100V: 5, 10, 20, 40, 80 W, bypass
  • Transformer Taps, 70V: 2.5 W, 5 W, 10 W, 20 W, 40 W, 80 W, bypass
  • Coverage, Vertical: 115°

Transducers:

  • Crossover Frequency: 1.7 kHz, passive 2-way crossover
  • Driver Protection: Recommended high-pass protection 60 Hz with recommended 24 dB/octave filter
  • High-Frequency Transducer Quantity and Size: 1 × 1.25 in (32 mm) neodymium dome tweeter, coaxially mounted, weather-treated
  • Low-Frequency Transducer Quantity and Size: 1 × 6.5 in (165 mm) woofer, weather-treated
}
