Apart Revamp 1120T 1Ch Power Amplifier, 1x120W, 100V/4-8 Ohms
The Apart Revamp 1120T is a professional 100V/4 Ohm 1Ch Class D power amplifier perfect for a range of high-end audio installations.
Class-D amplification - extremely efficient amplifier, silent operation, built-in cooling fan keeps the unit cool at all times.
High-end power amplifier designed for smaller single-zone audio installations.
Gain control for each channel located on the rear of the amplifier can be pre-set before installing to avoid volumes being exceeded.
- 1 x 120W @ 100V Line
- 1 x 120W @ 4 Ohms
- 1 x 60W @ 8 Ohms
- Unique and versatile Apart design
- 1 x 120 watts output power @ 100 volts (or @ 4 ohms)
- Class-D amplifier with a builtin galvanic separated toroidal output transformer
- Convection-cooled and excluded from cooling fans
- Reliable, maintenance-free, silent and dust-free
- Completely built in a 1U chassis without front control
If you require any assistance with any of our products then call us on 02476 369890 and one of our specialists will be happy to help. Or you can use our Request a call back form.
See SPECIFICATION tab for technical specs
Apart Revamp 1120T Power Amplifier
- Dynamic output power 4 ohms: 120 watts
- Dynamic output power 8 ohms: 60 watts
- Output power RMS 100 volts: 120 watts
- Power consumption (max): 200 watts
- Height- rack units (1U=44 mm): 1 U
- Power supply: 115 - 230 VAC
- Output voltage tappings: 100 - 70 - 50 - 35 volts - 4 ohms
- Line input balanced: 1
- Channel separation: > 65 dB @ 1 kHz
- Frequency response (in Hz): 50 - 20 k
- Applicable in 100V: Yes
- Net weight product (kg): 4.6
- RMS output power 4 ohms: 120 watts
- RMS output power 8 ohms: 60 watts
- Minimum impedance load per channel: 4 ohms
- 19" (483 mm wide) rack mounting: Yes
- Power supply technology: Switching mode power supply
- Output channels: 1
- Line input unbalanced: 1
- Power amp topology: Class-D
- Cooling system: Convectional
- Applicable low impedance: Yes
- Height: 44mm
- Depth (incl front): 239mm
- Depth (build in): 230mm
Apart Revamp 1120T - PDF Download
