Optimal Audio UP 6O - Full-Range Open-Backed 6.5" Passive Ceiling Speaker 60W

Sold out
Original price £126.00 (inc. VAT) - Original price £126.00 (inc. VAT)
Original price
£126.00 (inc. VAT)
£126.00 (inc. VAT) - £126.00 (inc. VAT)
Current price £126.00 (inc. VAT)
SKU OPAUP6OW
DETAILS

The UP 6O Ceiling Speaker operates at 70V, 100V and Low Impedance, delivering clear, consistent sound in commercial spaces with easy installation and versatile performance options.

The Up 6O offers a sleek and unobtrusive solution for delivering exceptional audio performance in various commercial settings. Whether it's hotels, retail spaces, bars, or restaurants, the Up 6O ensures consistent coverage and crystal-clear sound reproduction, catering to diverse environments while mindful of cost considerations.

With its integrated fixing system, installation is a breeze, ensuring a seamless and tidy setup. Supplied without a back can, the Up 6O is perfect for ceilings with a minimum cavity depth and blends effortlessly into any decor.

Powered by a 6.5" (162mm) driver, this speaker excels in both background music and speech projection. Its conical 110° coverage pattern ensures uniform sound dispersion throughout the designated area.

The Up 6O can be run on a series of 70 or 100 Volt taps or at low impedance. The 16 ohm setting allows up to four units to be connected to each amplifier channel at low impedance. Tap selection is via a rotary switch behind the removable grille.

For optimal performance and speaker protection, pairing the Up 6O with SmartAmps or Zone systems is recommended. With the Zone series, incorporating a ZonePad and utilizing the WebApp simplifies system setup and offers intuitive control for end users, enhancing overall user experience.


Optimal Audio UP 6O Key Features:

  • 6.5” coaxial driver
  • Discreet size without back can
  • Unobtrusive design
  • 16 ohm or 70V/100V line operation
  • Range of power taps
  • Wide conical coverage pattern
  • Integrated mounting hardware
SPECS & DOWNLOADS

Optimal Audio UP 6O Specifications

  • TYPE:  Two-way, full range, passive, ceiling speaker
  • FREQUENCY RESPONSE (with preset): 65Hz – 18kHz ± 3dB / -10dB @50Hz
  • DRIVERS:  LF: 6.5” (162mm), Coated paper / HF: 1" (25mm) exit / 0.7" (20mm) metal dome
  • RATED POWER:  60W (AES) 120W (Peak)
  • NOMINAL IMPEDANCE:  16Ω
  • SENSITIVITY (1W/1m):  90dB
  • MAXIMUM SPL:  108dB (cont), 111dB (peak)
  • CROSSOVER: 2.7kHz passive
  • RECOMMENDED HIGH-PASS FILTER:  24dB/octave @ 60Hz
  • TRANSFORMER TAPS @ 70V:  60, 30, 15, 7.5W
  • TRANSFORMER TAPS @ 100V:  60, 30, 15W
  • DISPERSION (-6dB):  110˚ conical
  • BAFFLE:  ABS
  • PROTECTIVE GRILLE:  Perforated steel
  • FIRE RATING: UL94-V0
  • CONNECTORS:  4 Pin Euroblock with link out
  • FITTINGS:  C-ring support backing plate
  • DIMENSIONS:  (Ø) 251mm x (D ) 103.5mm / (Ø) 9.88” x (D ) 4.1”
  • CUT-OUT DIAMETER:  222mm (8.74”)
  • WEIGHT:  2.24kg (4.94lbs)


      }
