Optimal Audio SUB-10 - 250W 10" Passive Cabinet Subwoofer

Sold out
Original price £510.00 (inc. VAT) - Original price £510.00 (inc. VAT)
Original price
£510.00 (inc. VAT)
£510.00 (inc. VAT) - £510.00 (inc. VAT)
Current price £510.00 (inc. VAT)


Compact yet powerful, the SUB 10 is ideal for Optimal Audio setups requiring increased impact and low-frequency.

The SUB-10 from Optimal Audio is a compact high-performance passive subwoofer designed to work perfectly alongside other Optimal Audio loudspeakers, such as the UP and Cuboid ranges.

This sub features a 10" (250mm) driver loaded into a plywood bass-reflex cabinet for maximum performance and a peak SPL of 127dB. It can be used as a freestanding unit, fixed to a wall or ceiling or flown using integral M6 inserts.

The driver is protected by an impact-resistant perforated steel grille, while rubberised feet on the base of the unit resist movement. The enclosure itself is constructed from plywood and finished in a textured black paint.


    AV Link Active Subwoofer

    • Type: Sub-bass loudspeaker
    • Frequency response (with preset): 50 - 150Hz ± 3dB -10dB @ 42Hz
    • Driver (LF): 10" (250mm)
    • Rated output power: 250W (AES) 1000W (Peak)
    • Nominal Impedance:
    • Sensitivity (1W/1m): 97dB (Half Space)
    • Maximum SPL: 121dB (cont) 127dB (peak) (Half Space)
    • Enclosure: Plywood
    • Finish: Black Textured Paint
    • Protective Grille: Perforated Steel
    • Connectors: Euroblock type
    • Fittings: 12 x M8, inset bolts
    • Dimensions: 470 x 297 x 353mm / (W) 18.50” x (H) 11.7” x (D) 13.9”
    • Weight: 12.9Kg (28.4lbs)

      AV Link Active Subwoofer - PDF Downloads

      Download the User Manual Here

      Download the Datasheet Here
