Monacor PA-704 35W 100V Mixer Amplifier with 12V/24V DC

by Monacor
£94.99 (inc. VAT)
SKU PA-704
DETAILS

The Monacor PA-704 is a compact 100V Mixer Amplifier that has 12V/24V power operation ideal for installation into vehicles or small venues.

With a 35W power output the PA-704 is capable of driving multiple background music speakers.

It can operate on both 100v or low impedance loudspeaker levels.

The PA-704 has a microphone input which has priority over the inputs; great for paging applications. An external media player such as a radio or phone can be connected to the Aux/Phono input on the back of the amplifier.

Comes with a 3-year manufacturers warranty.


Key features include:

  • 1 x 35 W
  • Silent operation due to fanless cooling concept
  • 2 low-impedance microphone inputs
  • 1 aux input, 1 phono input
  • Speaker outputs via screw terminals
  • Input and output level controls
  • 2-way tone control for the output
  • Connection for a microphone talk button to switch off the other sources during announcements
  • Mains operation and 12-24 V emergency power operation

All Monacor products have a 3 year warranty

All Monacor products carry an industry leading 3 year warranty

See SPECIFICATION tab for technical specs
SPECS & DOWNLOADS

Monacor PA-704 Mixer Amplifier

  • Peak output power: 70 W
  • Power rating: 35 W
  • Channels: 4
  • Inputs: 5 mV (mic), 210 mV (aux), 5 mV (phono)
  • Frequency range: 100-18,000 Hz
  • Equalizer bass: ±10 dB/150 Hz
  • Equalizer treble: ±10 dB/6 kHz
  • S/N ratio: > 55 dB
  • THD: < 1%
  • Mains voltage: ~ 230 V
  • Mains frequency: 50 Hz
  • Power consumption, operation: 100 VA
  • Operating voltage (possible alternative): DC 12-24 V
  • Power supply (possible alternative): DC 2.5 A
  • Admiss. ambient temp.: 0-40 °C
  • Width: 320 mm
  • Height: 85 mm
  • Depth: 230 mm
  • Weight: 4.97 kg
  • Connections: 2 x 6.3 mm jack (mic), 1 x RCA L/R (aux), 1 x RCA L/R (phono), connecting terminals (speakers)

Monacor PA-702 Mixer Amplifier - PDF file download

Download the User Manual HERE

Download Product Data Sheet HERE
