Monacor PA-5480 480W 100V PA Mixer Amplifier with 5-Zone Volume Control

by Monacor
Original price £689.00 (inc. VAT) - Original price £689.00 (inc. VAT)
Original price £689.00 (inc. VAT)
£689.00 (inc. VAT)
£689.00 (inc. VAT) - £689.00 (inc. VAT)
Current price £689.00 (inc. VAT)
SKU PA-5480

The Monacor PA-5480 is a 480W 100V Line Mixer Amplifier with 5-Zone volume attenuation; perfect for medium to large scale multi-zone audio PA.

    Some other key features include:

    • 1 x 480 W
    • 5 zones, can be controlled individually
    • Chime, wailing sound, automatic mute, chime and siren can also be activated via external momentary push-button, 2-tone chime or 4-tone chime (selectable)
    • Bass, treble and master controls, level display via LEDs, regulated fan
    • Insertions for various functions are available at option
    • 18 V phantom power for electret microphones
    • Connection for desktop microphone PA-5000PTT
    • Alarm announcement with insertion PA-1120DMT (available at option)
    • Mains operation and 24 V emergency power operation
    • Removable mounting brackets

    All Monacor products have a 3 year warranty

    All Monacor products carry an industry leading 3 year warranty

    See SPECIFICATION tab for technical specs


    Monacor PA-5480 Specifications

    • Peak output power: 680 W
    • Power rating: 480 W
    • Channels: 5
    • Zones: 5
    • Inputs: 2.5 mV/5 kΩ, 0.3 V/5 kΩ (mic/line), 0.3 V/15 kΩ (line), 0.775 V/10 kΩ (preamplifier)
    • Frequency range: 55-16,000 Hz
    • Equalizer bass: ± 10 dB/100 Hz
    • Equalizer treble: ± 10 dB/10 kHz
    • S/N ratio:  > 70 dBA (mic),> 80 dBA (line)
    • THD: < 1%
    • Phantom power: 18 V
    • Mains voltage: ~ 230 V
    • Mains frequency: 50 Hz
    • Power consumption, operation: 1,500 VA
    • Operating voltage (possible alternative): DC 24 V
    • Power supply (possible alternative): DC 40 A
    • Admiss. ambient temp.: 0-40 °C
    • Width: 482 mm
    • Height: 133 mm
    • Depth: 352 mm
    • Rack spaces, RS: 3
    • Weight: 17 kg

    Monacor PA-5480 Mixer Amplifier - PDF file download

    Download the PDF Product Data Sheet HERE

    Download the PDF Manual HERE
