Marantz Cinema 60 Specifications

Download the PDF User Guide HERE >

• Number of Powered Channels: 7
• Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive): 100 W
• Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive): 140 W
• Power Output (6 ohm, 1 kHz, 10% 1ch Drive): 200 W
• 70% Guarantee: Yes
• Discrete Power Amplifier: Yes
• Amplifier Topology: Class A/B
• Current Feedback Topology: Yes
• Bi-Amp Drive: assignable

• DTS: DTS HD Master, DTS:X, DTS Neural:X, DTS Virtual:X
• Dolby: Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music, Dolby Surround
• Max Number of Processing (Preamp) Channels: 7.1

• Composite In / Out: 0/0
• Component In / Out: 0/0
• HDMI In / Out: 6 / 2
• Multi-Room Video Out via HDMI: No
• Analog In / Fixed Level Out: 4 in / 0 out
• Phono (MM) In: Yes
• Digital In: Optical / Coaxial: 2 / 2
• Multi-Room Out: analog / digital: 1 / 0
• Multichannel Preamp Out: 7.2
• Subwoofer Out: 2
• 7.1 multichannel input: No
• Number of Speaker Terminals: 7
• Speaker A / B: assignable
• Multi-Room Speaker Terminal: assignable
• Front Inputs: USB-A
• USB Audio / Made for iPod / Made for iPhone: Yes / No / No
• AM/FM Tuner: Yes

• Total HDMI Inputs / No. Support 8K: 6 / 3
• HDCP2.3 support: Yes
• HDMI Outputs: Main / Zone: 2 / 0
• Analog to HDMI Video Conversion: No
• HDMI Upscaling: 1080P/4K to 8K
• Max resolution @ framerate: 8K/60Hz, 4K/120Hz
• Audio Return Channel: ARC, eARC
• Video Dynamic Range: HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR
• ALLM (Auto Low Latency Mode) Pass-through for gaming: Yes
• Variable Refresh Rate / Quick Frame Transport: Yes / Yes
• HDMI Pass-Through in Standby Mode: Yes
• CEC: Yes
• DSD Audio over HDMI: No
• Auto LipSync: Yes

• Copper Plated Chassis: No
• Toroidal Power Supply Transformer: No
• Hyper Dynamic Amplifier Modules (HDAM) (List version): Yes
• Pure Direct Mode: Yes
• Gold Plated RCA Terminals: No
• Clock Jitter Reducer: No

• Audyssey: MultEQ XT
• Audyssey Dynamic EQ / Dynamic Volume: Yes / Yes
• Audyssey LFC: No
• Dirac Live Support: No
• Variable Cross Over: Yes
• Optimized Bass Redirection: Yes
• Bass Sync: No

• Lossy Formats: MP3 / WMA / AAC
• Lossless formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24
• DSD Audio: 2.8 MHz / 5.6MHz
• Gapless Playback: FLAC, WAV ,ALAC ,DSD
• Compressed Audio Enhancer: MDAX2: Yes
• Network Audio Sharing: Yes

• HEOS Multi-room and Streaming: Yes
• AirPlay Audio Streaming: AirPlay 2
• Internet Radio: TuneIn
• Spotify*: Spotify Connect
• Pandora: No
• SiriusXM: Yes
• Other Streaming Services *: Amazon Music HD/
  Amazon Music / TIDAL / Deezer / iHeart Radio / Napster / SoundCloud / Mood Mix
• Roon tested: Yes

• Ethernet Ports: Yes
• Wi-Fi (include version / band): Yes
• Bluetooth (Include version): Yes
• Bluetooth Re-transmit for Bluetooth headphones: Yes

• Voice Assistant Compatibility: Alexa / Google Voice Assistant / Apple HomePod
• App for Smart Phones & Tablets (iOS & Android): Marantz AVR Remote App, HEOS
• HEOS Multi-Room Integrated: Yes
• HEOS Link Compatibility: IR/ IP: Yes / Yes
• Multi-Room zones: 2
• Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog: 2 Ch / 2Ch / Yes / Yes
• Zone Audio Output: Speaker / Preout: Yes / Yes
• Zone HDMI Output from HDMI Source: No
• Control Connectivity: IP Control / RS232 Control / Web Control / App Control
• IR Flasher In: Yes
• Marantz Remote Bus: Yes
• DC Trigger Output: 1
• HDMI Diagnostics: Yes

• Front Display: port hole OLED
• GUI Languages: 3
• Setup Assistant: Yes
• Smart Select on Remote: Yes
• Firmware Update by Network / USB: Yes / Yes
• ECO Mode: Yes
• Auto Power off: Yes
• Sleep Timer: Yes

• Available colours: Black
• Metal Front Panel: No
• System Remote Control: RC049SR
• Power Consumption in W: 650
• Power Consumption No-Sound (ECO on/off) in W: 45/ 75
• Standby Consumption in W: 0.2
• CEC Standby Consumption in W: 0.5
• Network Standby Consumption in W: Less than 2.0
• Maximum Dimensions:
  Antenna:Horizontal:(W x D x H) in mm
  Antenna:Vertical :(W x D x H) in mm
  W/o Antenna:(W x D x H) in mm442 x 354 x 165
  ( 442 x 354 x 235 )
  【 442 x 343 x 165 】
• Weight in kg: 10.9
• What's in the box: Main unit, remote control, batteries, AM/FM antennas, wire labels, quick start guide, Audyssey microphone, card board microphone stand, 2 External Detachable Antenna, AC cord

AudioKraft PCS-60 Ceiling Speaker Specifications

Download the PDF Manual HERE >

• Nominal Impedance:    8Ω
• Power (RMS):     60W
• Driver:     6.5 inch
• Driver Material:     Kevlar Woven Cone
• Single Tweeter:     0.75 inch
• Tweeter Material:     Titanium Dome
• Frequency Response (±3db):     60 Hz-20 kHz
• Efficiency:     90dB
• Colour:     White (RAL 9010)
• Dimension:     Ø 227mm x 87mm
• Cut-out Size:     Ø 210mm
• Weight (Net):     1.52kg
• Weight (Gross):     2.00kg

Q Acoustics 3060S Active Subwoofer Specifications

• Enclosure type: Infinite Baffle
• Bass Unit: 200 mm (8 in)
• Frequency Response (+3 dB, -6 dB): 35 – 250 Hz
• Internal Amplifier Power: 150 W Class D
• Crossover Frequency: 35 – 250 Hz (var)
• Effective Volume: 10.6 L (647 cu in)
• Dimensions H/W/D cabinet: 300 x 480 x 150 mm (11.8 x 18.9 x 5.9 in)
• Dimensions H/W/D overall: 324 x 480 x 155 mm (12.8 x 18.9 x 6.1 in) overall
• Weight (per speaker): 8.5 kg (18.7 lbs)

AudioKraft Clarion Speaker Cable Specifications

• CSA: 2.5mm
• Strands: 2 x (79 x 0.2mmØ)2 x (79 x 0.2mmØ)
• Dimensions: 4.5 x 9.0mm
• Current: 25A max
