Clever Acoustics CS 56LC 5" 6W 100V Ceiling Speaker

£9.95 (inc. VAT)
SKU CRSP09

DETAILS

The Clever Acoustics CS 56LC is a 5" 6W 100V Line ceiling speaker perfect for background music & speech applications.

This low-profile ceiling speaker boasts a slimline design that blends into environments perfect for discreet installation.

The CS 56LC features a dual-cone driver for extended upper-frequency response ensuring maximum sound quality.

The CS 56LC operates on 100V Line and has multiple power tappings of 6W, 3W, 1.5W.

Installation is made quick and easy thanks to spring clip mounting clips. The speaker is also supplied with a cut-out template to aid installation.

Key Features

  • 3 year warranty
  • Dual cone driver for extended upper frequency response
  • Multiple power taps
  • Low profile design blends into environments
  • ABS baffle with metal grille
  • Spring clip mounting for easy installation
  • Supplied with template to aid installation
    SPECS & DOWNLOADS

    Clever Acoustics CS 56LC Specifications

    • Input: 70V, 100V
    • Power taps @ 100V: 1.5W, 3W, 6W
    • Power taps @ 70V: 0.75W, 1.5W, 3W
    • Impedance: 1.7KΩ, 3.3KΩ, 6.7KΩ
    • Sensitivity (1W/1m): 89dB (±3dB)
    • Maximum SPL (Rated W/1m): 96dB
    • Frequency response: 80Hz-18kHz
    • Drivers: 5" full range dual cone
    • Connections: Flying leads
    • Cutout: 145mmØ
    • Mounting depth: 70mm
    • Dimensions: 76 x 170mmØ
    • Weight: 0.75kg

                Clever Acoustics CS 69LC PDF Downloads

                Download the User Manual Here
