Bosch Plena PLE-1MA030 30W Public Address Mixer Amplifier, 100V / 8 Ohms
DETAILS
The Bosch Plena PLE-1MA030 is a versatile 30-watt public address mixer amplifier, ideal for both 100-volt line and 8-ohm sound systems.
Ideal for small to medium-sized environments such as retail stores, office buildings, schools, and public spaces, the PLE-1MA030 delivers superior sound quality and excellent speech intelligibility.
Built with Bosch’s renowned engineering, this amplifier offers a simple yet powerful solution for paging, background music, and emergency announcements.
Bosch Plena PLE-1MA030 Key Features:
-
30-Watt Output Power
Delivering 30 watts of power, the Bosch PLE-1MA030 is perfect for commercial audio systems that require consistent, clear sound over a large area. Whether used with 100V line loudspeakers or 8-ohm systems, it offers flexible installation options to suit various environments, ensuring optimal coverage for both background music and speech applications. -
Multiple Input Options
The PLE-1MA030 features 4 low-noise balanced microphone/line inputs with phantom power, allowing for clear and professional-quality sound, ideal for paging and announcements. In addition, there are 3 dedicated line inputs for music sources and other audio devices, offering versatility for both background music and paging. The unit also includes a 100V input and a telephone input, both with priority settings, making it suitable for integration into larger paging or emergency systems. -
Priority Paging and Emergency Override
Equipped with a range of priority features, including voice-activated emergency override and priority paging, the PLE-1MA030 ensures that important messages can always take precedence. This makes it particularly suited for environments where announcements need to cut through background noise or music, such as in emergency situations or high-traffic areas. -
Smart Equalizing and Sound Clarity
Bosch’s intelligent equalizing technology enhances both music and speech reproduction, ensuring high-quality audio performance regardless of the acoustic environment. Built-in limiters help prevent distortion, maintaining clarity and precision, especially for important announcements. The amplifier’s LED VU meter provides a visual indication of audio levels, helping operators maintain the perfect volume. -
Ease of Use
One of the standout features of the PLE-1MA030 is its user-friendly design. Included in the package are zone labels and setting indicators, allowing installers to customize volume and tone controls with colour markers for easy identification of optimal and maximum volume levels. This simplifies operation, ensuring that non-technical users can manage the system without confusion. Additionally, a built-in chime feature can be activated for attention-grabbing announcements. -
Flexible Installation and Power Options
The PLE-1MA030 is designed to be adaptable to different installation setups. It can be rack-mounted using the 19" brackets that come included, making it a convenient addition to any professional AV rack system. Furthermore, the amplifier can run on both standard AC power and 24V DC, offering flexibility in different power environments, including backup power systems during emergencies. -
Robust and Reliable
Built to last, the Bosch PLE-1MA030 features a rugged design and a 3-year warranty, ensuring dependable performance over time. Compliant with international installation and safety standards, it is a trusted choice for demanding commercial installations.
Bosch PLE-1MA030 Plena Applications:
Whether used for voice paging, background music, or emergency evacuation systems, the Bosch PLE-1MA030 is the ideal solution for a range of environments, including:
- Retail stores and shopping centres
- Office buildings and corporate environments
- Schools, universities, and educational facilities
- Public transportation hubs and stations
- Healthcare facilities and hospitals
- Hotels, restaurants, and entertainment venues
SPECS AND DOWNLOADS
Download the Bosch PLE-1MA030 PDF Spec Sheet HERE >
Bosch PLE-1MA030 Mixer Amplifier Specifications
Mains power supply:
- Voltage: 230 VAC ±10%, 50/60 Hz (reduced power at lower mains or battery voltage)
- Inrush current: 4.5A
- Power consumption: 100 VA
Performance:
- Frequency response: 50 Hz to 20 kHz (+1/‑3 dB @ ‑10 dB ref. rated output)
- Distortion: <1% @ rated output power, 1 kHz
- Bass Control: Max -12/+12 dB (frequency is setting dependent)
- Treble Control: Max -12/+12 dB (frequency is setting dependent)
- RJ-45 input: 1 x
- Wall panel input: For PLE‑WP3S2Z
- Mic / Line Input: 4 x
- Music input: 3 x
- Emergency / telephone: 1 x
- Master/music output: 1 x
- Loudspeaker output 100 V: Euro style pluggable screw terminal, floating
- Max / rated PLE-1MA030: 45 W / 30 W
- Loudspeaker output 4 ohm: 300kohm
- Connector: Euro style pluggable screw terminal, floating
- PLE-1MA030-EU: 11 V (30 W)
Physical:
- Dimensions (H x W x D): 100 x 430 x 270 mm (19" wide, 2U high)
- Mounting: Stand-alone, 19" rack
- Colour: Charcoal
- Weight: Approx. 5 kg
