Bosch Plena PLE-1ME240 240W Mixer Amplifier, 100V / 4 Ohms
DETAILS
The Bosch PLE-1ME240 is a powerful 240-watt mixer amplifier designed for versatile use in both 100-volt line and 4-ohm sound systems.
Ideal for large commercial spaces and public address applications, this amplifier ensures clear audio quality for announcements, background music, and more.
With Bosch's reputation for performance and durability, it is an excellent choice for various audio environments.
Bosch Plena PLE-1ME240 Key Features:
-
240-Watt Output Power
The PLE-1ME240 delivers a robust 240 watts of power, making it suitable for larger venues that require comprehensive sound coverage. Whether connected to 100V line loudspeakers or 4-ohm systems, this amplifier provides powerful and clear audio for various applications. -
Flexible Input Options
Equipped with four switchable balanced microphone/line inputs, the PLE-1ME240 caters to a variety of audio sources. Phantom power is available for condenser microphones, ensuring professional-quality sound for speeches and announcements. Additionally, a separate music input with volume control allows for seamless integration of music sources. -
Priority Paging and Chime
The amplifier includes a contact closure activation feature for Input 1, allowing it to take priority over all other microphone and music inputs. This functionality is essential for paging applications, ensuring that urgent messages are communicated clearly. A built-in pre-announcement chime adds an extra layer of functionality, signaling upcoming announcements effectively. -
User-Friendly Design
The PLE-1ME240 is designed with ease of use in mind. Its straightforward layout and labeling make it easy for non-technical users to operate. The amplifier includes an announcement-only output with a 3-wire volume override, ensuring flexibility in how audio is managed across different settings. -
Reliable and Built to Last
As part of Bosch's commitment to quality, the PLE-1ME240 comes with a 3-year warranty, ensuring it will deliver reliable performance over time. Its robust construction meets international safety and installation standards, making it an excellent investment for commercial audio systems.
Bosch Plena PLE-1ME240 Applications:
The Bosch PLE-1ME240 is ideal for environments where clear, powerful sound is essential, including:
- Large retail stores and shopping centres
- Conference centres and corporate offices
- Educational institutions and lecture halls
- Healthcare facilities and waiting areas
- Larger venues and event spaces
SPECS AND DOWNLOADS
Download the Bosch Plena PLE-1ME240 PDF Spec Sheet HERE >
Bosch Plena PLE-1ME240 Mixer Amplifier Specifications
Mains power supply:
- Voltage: 230 VAC ±10%, 50/60 Hz (reduced power at lower mains or battery voltage)
- Inrush current: 12A
- Power consumption: 800 VA
Performance:
- Frequency response (Line): 60 Hz to 20 kHz (+1/‑3 dB @ ‑10 dB ref. rated output)
- Frequency response (Mic.): 70 Hz to 20 kHz (+1/‑3 dB @ ‑10 dB ref. rated output)
- Distortion: <1% @ rated output power, 1 kHz
- Bass Control: Max. ± 8 dB
- Treble Control: Max. ± 8 dB
- Mic./Line input: 4 x
- Input 1 (push-to-talk contact with priority): 5‑pin Euro style, balanced, phantom
- Input 2: 3‑pin Euro style, balanced, phantom
- Input 3 and 4: TRS Jack (1/4, 6.3mm) balanced
- Sensitivity: 1 mV (mic.); 300 mV (line)
- Impedance: >1 kohm (mic.); >5 kohm (line)
- Dynamic range: 93 dB
- S/N (flat at max volume): >63 dB (mic.); >70 dB (line)
- S/N (flat at min volume/muted): >75 dB
- CMRR (mic.): >40 dB (50 Hz to 20 kHz)
- Headroom: >25 dB
- Speech filter: -3 dB @ 315 Hz, high-pass, 6 dB/oct
- Phantom power supply: 16 V via 1.2 kohm (mic.)3
Music input:
- Connector: Cinch, stereo converted to mono
- Sensitivity: 200 mV
- Impedance: 22 kohm
- S/N (flat at max volume): >75 dB
- S/N (flat at min volume/muted): >80 dB
- Headroom: >25 dB
Loudspeaker output:
- Connector: Screw terminal, floating
- Max / rated PLE-1ME240‑xx: 360 W / 240 W
- Loudspeaker output: 4 ohm
- Connector: Screw terminal, floating
Physical:
- Dimensions (H x W x D): 100 x 430 x 270 mm (19" wide, 2U high)
- Mounting: Stand-alone, 19" rack
- Colour: Charcoal
- Weight: Approx. 10.50 kg
