Bosch Plena PLE-1ME060 60W Mixer Amplifier, 100V / 4 Ohms
DETAILS
The Bosch Plena PLE-1ME060 is a 60-watt mixer amplifier designed for versatile use in both 100-volt line and 4-ohm sound systems.
Ideal for commercial and public address applications, this reliable amplifier ensures clear audio quality for announcements and background music.
With Bosch's commitment to performance and durability, it is a dependable choice for various audio environments.
Bosch Plena PLE-1ME060 Key Features:
-
60-Watt Output Power: The PLE-1ME060 delivers 60 watts of power, making it suitable for smaller venues that require effective sound coverage. Whether connected to 100V line loudspeakers or 4-ohm systems, this amplifier provides clear and powerful audio for announcements and music playback.
-
Flexible Input Options: Equipped with four switchable balanced microphone/line inputs, the PLE-1ME060 caters to a variety of audio sources. Phantom power is available for condenser microphones, ensuring professional-quality sound for speeches and announcements. Additionally, a separate music input with volume control allows for easy integration of music sources.
-
Priority Paging and Chime: The amplifier includes a contact closure activation feature for Input 1, allowing it to take priority over all other microphone and music inputs. This functionality is essential for paging applications, ensuring that urgent messages are communicated clearly. A built-in pre-announcement chime adds an extra layer of functionality, signalling upcoming announcements effectively.
-
User-Friendly Design: The PLE-1ME060 is designed with ease of use in mind. Its straightforward layout and labelling make it easy for non-technical users to operate. The amplifier includes an announcement-only output with a 3-wire volume override, ensuring flexibility in how audio is managed across different settings.
-
Reliable and Built to Last: As part of Bosch's commitment to quality, the PLE-1ME060 comes with a 3-year warranty, ensuring it will deliver reliable performance over time. Its robust construction meets international safety and installation standards, making it an excellent investment for commercial audio systems.
Bosch Plena PLE-1ME060 Applications:
The Bosch PLE-1ME060 is ideal for environments where clear, powerful sound is essential, including:
- Retail stores and shopping centres
- Conference rooms and corporate offices
- Educational institutions and lecture halls
- Healthcare facilities and waiting areas
- Small venues and event spaces
SPECS AND DOWNLOADS
Download the Bosch Plena PLE-1ME060 PDF Spec Sheet HERE >
Bosch Plena PLE-1ME060 Mixer Amplifier Specifications
Mains power supply:
- Voltage: 230 VAC ±10%, 50/60 Hz (reduced power at lower mains or battery voltage)
- Inrush current: 5A
- Power consumption: 200 VA
Performance:
- Frequency response (Line): 60 Hz to 20 kHz (+1/‑3 dB @ ‑10 dB ref. rated output)
- Frequency response (Mic.): 70 Hz to 20 kHz (+1/‑3 dB @ ‑10 dB ref. rated output)
- Distortion: <1% @ rated output power, 1 kHz
- Bass Control: Max. ± 8 dB
- Treble Control: Max. ± 8 dB
- Mic./Line input: 4 x
- Input 1 (push-to-talk contact with priority): 5‑pin Euro style, balanced, phantom
- Input 2: 3‑pin Euro style, balanced, phantom
- Input 3 and 4: TRS Jack (1/4, 6.3mm) balanced
- Sensitivity: 1 mV (mic.); 300 mV (line)
- Impedance: >1 kohm (mic.); >5 kohm (line)
- Dynamic range: 93 dB
- S/N (flat at max volume): >63 dB (mic.); >70 dB (line)
- S/N (flat at min volume/muted): >75 dB
- CMRR (mic.): >40 dB (50 Hz to 20 kHz)
- Headroom: >25 dB
- Speech filter: -3 dB @ 315 Hz, high-pass, 6 dB/oct
- Phantom power supply: 16 V via 1.2 kohm (mic.)3
Music input:
- Connector: Cinch, stereo converted to mono
- Sensitivity: 200 mV
- Impedance: 22 kohm
- S/N (flat at max volume): >75 dB
- S/N (flat at min volume/muted): >80 dB
- Headroom: >25 dB
Loudspeaker output:
- Connector: Screw terminal, floating
- Max / rated PLE-1ME060‑xx: 90 W / 60 W
- Max / rated PLE-1ME240‑xx: 360 W / 240 W
- Loudspeaker output: 4 ohm
- Connector: Screw terminal, floating
Physical:
- Dimensions (H x W x D): 100 x 430 x 270 mm (19" wide, 2U high)
- Mounting: Stand-alone, 19" rack
- Colour: Charcoal
- Weight: Approx. 6.5 kg
