Adastra RM120D 120W 4-Zone 100V Line Mixer Amplifier with Bluetooth & DAB
BLACK FRIDAY - Use code BF10 at checkout
Save an EXTRA 10% sitewide, including Sale items!
DETAILS
The new updated RM120D amplifier by Adastra is a 5-channel, 4-Zone mixer amp that features DAB+ Radio & Bluetooth connectivity.
The Adastra RM120D is a powerful and versatile mixer amplifier that offers a wide range of features for commercial and mobile PA applications. With a total power output of 120 watts, this 100V amplifier can drive an array of speakers and provide high-quality audio for large multi-zone spaces.
One of the most notable features of the RM120D is its DAB+ radio and Bluetooth connectivity. Users can easily stream music wirelessly from their smartphones, tablets, or other devices, giving them access to a wide range of music and audio content. The Bluetooth receiver features a unique pairing ID, which is ideal for commercial environments as it prevents members of the public from being able to connect.
Additionally, the RM120D also has a built-in media player with a USB/SD card reader which supports MP3 and WAV files.
The Adastra RM120D can be powered via 240V mains or 24Vdc meaning it can be run from a leisure battery; perfect for mobile PA applications such as sports grounds & school fields, equestrian centres, floats & Santa sleighs.
The RM120D has 4 switchable zonal outputs that enable users to isolate certain areas, and switch them off when not in use. Alternatively, it features a single 120W output for applications that do not require zonal control.
It also has 24V emergency mute contacts for the connection of a fire alarm. When an alarm is sounded the amplifier will shut down ensuring a safe and efficient evacuation.
The 2U rack-mountable design makes it easy to install and integrate into any system.
Adastra RM120D Key Features:
- DAB+/FM radio tuner
- Bluetooth received with unique pairing ID
- USB/SD audio player
- 4 switchable 100V outputs and 1 unswitched output
- Optional 4-16 Ohm output
- XLR input with switchable +20V phantom power
- 2 x mic/line inputs, 2 x RCA line inputs, 1 x RCA line output
- Switchable VOX voiceover feature
- 2U 19" rack-mountable (rack ears supplied)
- 24V emergency mute contacts
- Mains 230Vac or 24Vdc power operation
SPECS & DOWNLOADS
Download the PDF User Manual HERE >
Adastra RM120D Mixer Amplifier Specifications
-
Mains power: 110/240Vac, 50/60Hz (IEC)
- DC power: 24Vdc (screw terminals)
- Inputs: Mic XLR, 2 x mic/line jack, 2 x RCA line
- Input sensitivity : mic 1 (balanced): -53dBV
- Input impedance : mic: 1 5k Ohms
- Input sensitivity : line (unbalanced): -15dBV (-18.5dBV line 5)
- Input impedance : inputs: 2-5 1k Ohms
- Line output: RCA
- Controls: Mic1, mic/line2+3, line4+5, bass, treble, master volume
- Equalizer : bass: 100Hz ±10dB
- Equalizer : treble: 10kHz ±10dB
- Rear panel switches: Phantom, Vox, Mic/Line (2 + 3)
- Phantom power: +20V (mic 1 input)
- Audio source: USB/SD player, DAB tuner and Bluetooth receiver
- Emergency control: 24V contacts - mute all except Mic.1 when triggered
- Bluetooth version: 5.0
- THD: <1.0%
- Power : output: 120Wrms
- Speaker : outputs: 100V / 4-16 Ohms / COM terminals
- Weight: 6.36kg
- Dimensions: 433 x 320 x 89mm
